| Single output type |
 |
|
| Model: 0055A SERIES (40 Watt.) |
|
¡ö |
INPUT VOLTAGE:AC 100-240V |
¡ö |
WEIGHT:166g APPROXIMATELY |
|
¡ö |
CASE SIZE:45.4mm x 27.8mm x95.4mm |
|
|
| |
|
| |
MODEL |
DC OUTPUT |
|
|
|
|
|
|
|
|
|
0055-050400 |
5V |
4.0A |
|
|
|
|
|
|
|
|
|
0055-060350 |
6V |
3.5A |
|
|
|
|
|
|
|
|
|
0055-070330 |
7V |
3.3A |
|
|
|
|
|
|
|
|
|
0055-080320 |
8V |
3.2A |
|
|
|
|
|
|
|
|
|
0055-090310 |
9V |
3.1A |
|
|
|
|
|
|
|
|
|
0055-100280 |
10V |
2.8A |
|
|
|
|
|
|
|
|
|
0055-110260 |
11V |
2.6A |
|
|
|
|
|
|
|
|
|
0055-120250 |
12V |
2.5A |
|
|
|
|
|
|
|
|
|
0055-130240 |
13V |
2.4A |
|
|
|
|
|
|
|
|
|
0055-140230 |
14V |
2.3A |
|
|
|
|
|
|
|
|
|
0055-150220 |
15V |
2.2A |
|
|
|
|
|
|
|
|
|
0055-160210 |
16V |
2.1A |
|
|
|
|
|
|
|
|
|
0055-170200 |
17V |
2.0A |
|
|
|
|
|
|
|
|
|
0055-180195 |
18V |
1.95A |
|
|
|
|
|
|
|
|
|
0055-190193 |
18.5V |
1.93A |
|
|
|
|
|
|
|
|
|
0055-200190 |
19V |
1.9A |
|
|
|
|
|
|
|
|
|
0055-210188 |
19.5V |
1.88A |
|
|
|
|
|
|
|
|
|
0055-220185 |
20V |
1.85A |
|
|
|
|
|
|
|
|
|
0055-230180 |
21V |
1.80A |
|
|
|
|
|
|
|
|
|
0055-240175 |
22V |
1.75A |
|
|
|
|
|
|
|
|
|
0055-230170 |
23V |
1.70A |
|
|
|
|
|
|
|
|
|
0055-240165 |
24V |
1.65A |
|
|
|
|
|
|
|
|
|
|
| |
|
| |
|
